Xe nâng bán tự động lớn

Liên hệ
Tình trạng: Còn hàng | Mã SP:
Xe nâng bán tự động Noblift Cấu tạo xe...



Xe nâng bán tự động Noblift

Cấu tạo xe nâng bán tự động Noblift 1500 kg

Thông số kỹ thuật xe nâng bán tự động Noblift

Residual Capacity at different lifting height 1KG=2.2LB 1INCH=25.4MM
Up to h3 mm ACTUAL CAPACITY (Q)kg
1600 1500
2500 1500
3000 800
Load centre distance (C)mm 600



Technical Data 1KG=2.2LB 1INCH=25.4MM
Identification 1.2 Model of manufacture   SPM1516 SPM1525 SPM1530 SPM1535 SPM1529FFL
1.3 Drive:(electric-battery or mains,diesel, petrol,fuel gas,manual)   manual
1.4 Type of operation(hand, pedestrian, standing, seated, order picker)   Pedestrian
1.5 Load Capacity /rated load Q(Kg) 1500
1.6 Load center distance C(mm) 600
1.9 Wheelbase y(mm) 1160
Weights 2.1 Weight(including battery) Kg 436 516 543 570 554
Wheels,
Chassis
3.1 Tyres(solid rubber, superelastic, nylon, polyurethane)   Nylon/PU
3.2 Tyre size,front mm 180×50
3.3 Tyre size,rear mm 74×70
3.5 Wheels, number front/rear   2/4
3.6 Track width,front b10(mm) 658
3.7 Track width,rear b11(mm) 390/490
Basic Dimensions 4.2 Lowered mast height h1(mm) 1980 1780 2030 2280 1980
4.3 Free lift h2(mm) -- -- -- - 1440
4.4 Lift height h3(mm) 1600 2500 3000 3500 2900
4.5 Extended mast height h4(mm) 1980 3020 3520 4020 3420
4.9 Height of handle min./max. H14(mm) 790/1156
4.15 Fork height lowered h13(mm) 85
4.19 Overall length L1(mm) 1720/1580
4.2 Length to face of forks L2(mm) 610/670
4.21 Overall width b1(mm) 762
4.22 Fork dimensions s/e/l(mm) 60/182/1100
60/150/900
4.25 width over forks b5(mm) 570
330-640
4.33 Aisle width for pallets 1000×1200 crossways Ast(mm) 2145
4.34 Aisle with for pallets 800×1200 lengthways Ast(mm) 2175 2145
4.35 Turning radius Wa(mm) 1280 1280
Performance 5.2 Lift speed, laden/unladen mm/s 65/100 72/112
5.3 Lowering speed, laden/unladen mm/s 85/70 96/80
5.11 Parking brake   Manual
E-Motor 6.2 Lift motor rating at S3 15% kw 1.5
6.4 Battery voltage, norminal capacity K5 V/Ah 12/150
6.5 Battery weight Kg 45
